LX WP200-II Spa Pump - 2HP - 2 Speed

79mm Centre Suction x 79mm Side Discharge

Extended 1 Year Warranty

In addition to the manufacturers standard warranty (usually 1 year) we also offer the opportunity for you to extend this warranty by a further 1 year (There is usually a one off fee to pay unless we are running a promotion) This can be arranged at the point of purchase or within a limited time afterwards.
Promotions - From time to time we run a promotiont to include a FREE 1year Extended Warranty on select products. If an item is eligible for a FREE extended warranty then this will be displayed on the product listing & will be noted in your basket.
An extended warranty is an easy way to protect your purchase, against any manufacturing defects causing breakdown. You will benefit from free repairs for the term of the warranty period & If your equipment can't be repaired then we will replace it free of charge.(A delivery surcharge may apply for non UK mainland addresses)
This warranty and the standard manufacturer’s warranty does not cover general wear and tear, abuse or misuse or incorrect installation.
If you would like any further information on our extended warranty scheme please call our Hydrospares team on 01326 371 483 OR email us at info@justspaparts.co.uk

LID: 19393
Extended Warranty Included Extended
Warranty
Included
WP200-II
Two Speed
2HP
2" x 2" (79mm x 79mm)
£249.98 Inc VAT
( £367.62)
PMP-5760
WP200-II
20 In StockSame day dispatch if ordered by 14:00
Special Offer - Free Extended 1 Year Warranty included - worth £50.00
Fast UK Delivery
Extended Warranty Available
Extended Warranty Included
Free warranty is included with this purchase
Spare Parts Available
Spare Parts Available
Browse spare parts
LX WP200-II Spa Pump - 2HP - 2 Speed
£249.98
RRP £367.62

The WP series of pumps will often serve as a circulation and booster pump, the low speed will circulate to heat and run filter cycles while the high speed will deliver a higher volume of water through hot tub jets.

If you require a 1 speed pump from LX this would be the LP pump series. Please see our other listings for these.

This is a direct replacement for LX WP200 Two Speed Spa Pump with 2" connections manufactured AFTER / POST 2008 (See IMPORTANT NOTE below)

Replacement for the following Jacuzzi models:

  • 6500-319
  • 6500-319
  • 6500-299
  • 6500-291
  • 6500-899

IMPORTANT NOTE: 2008 LP & WP pumps and wet ends are manufactured with a shorter suction (approx. 15mm) and discharge port (approx. 30mm). You may find on some hot tubs with very rigid plumbing that the newer versions will not line up with pipework. The wet end faceplate moulding is different and they are also "open" on the rear of the wet end casing as opposed to the pre 08 wet ends which are encased. SEE IMAGES FOR REFERENCE.

Model Information
Dimensions L x W x H 445x235x305mm
HEAD - H max 14 / 3.5m
FLOW - Q max 620 / 280lpm
Type / Speed 2 Speed
Model WP
Horsepower 2.5 Hp
MPN WP200-II
Motor Information
Amp Draw 7 / 2 A
Power - P1 1.5 / 0.35 kW
RPM 2900 / 1450
Capacitor Size(s) 30 µF
Wet End Information
Impeller Part No. B351-21
Impeller Diameter 107mm
Impeller Vane Gap 11.5mm
Shaft Seal Type Type A
Spare Parts Available Yes - See Spare Parts List
Dimensions
Spare Part Diagram
More Info

Pump Specifications

Dimensions

  • 445 x 250 x 305 (mm)

Summary

  • High Speed: 2HP / 1.5kW
  • Low Speed: 0.37HP / 0.35kW
  • Max. Head: 14 m
  • Max. Flow: 620 L/min
Spares
COMPARE LX Wet End Assembly - 2HP - 2" x 2"
LX Wet End Assembly - 2HP - 2" x 2"
For Use with LP200/ WP200 - Post 2008
29 In StockSame day dispatch if ordered by 14:00
QF: WET-5802
£81.58
RRP: £104.59
COMPARE LX Pump Shaft Seal - Type A
LX Pump Shaft Seal - Type A
For JA, LP & WP Series
23 In StockSame day dispatch if ordered by 14:00
QF: PMS-7397
£27.31
RRP: £34.14
COMPARE LX Motor Cooling Fan - 156mm
LX Motor Cooling Fan - 156mm
Most Large LX Motors - Black
Out of Stock - Available to Pre-Order10 on order - estimated 09/10/2024
QF: FAN-5847
£4.20
RRP: £4.99
COMPARE LX Fan Cover
LX Fan Cover
For LP Series & JA200/TDA150/TDA200
7 In StockSame day dispatch if ordered by 14:00
QF: FAN-5851
£7.99
COMPARE LX LP200 & WP200 Impeller
LX LP200 & WP200 Impeller
2Hp
Out of Stock - Available to Pre-Order50 on order - estimated 09/10/2024
QF: IMP-5809
£8.70
COMPARE LX O-Ring - 70mm
LX O-Ring - 70mm
For LP/WP Pump Unions
383 In StockSame day dispatch if ordered by 14:00
QF: ORG-5860
£6.99
COMPARE LX O-Ring - 150mm
LX O-Ring - 150mm
LP / WP - Wet End Face Plate
8 In StockSame day dispatch if ordered by 14:00
QF: ORG-5807
£11.49
COMPARE LX Drain Plug + O-Ring
LX Drain Plug + O-Ring
LP & WP Wet Ends
Special Order ItemLead time to be confirmed
QF: PLU-5806
£5.49
RRP: £6.46
COMPARE LX Cross Head Screw - M5 x 15mm
LX Cross Head Screw - M5 x 15mm
LP / WP / EA Face Plates
86 In StockSame day dispatch if ordered by 14:00
QF: SCR-5808
£0.99
COMPARE HS PRO - Motor Run Capacitor - 30µf
HS PRO - Motor Run Capacitor - 30µf
Flying Lead
8 In StockSame day dispatch if ordered by 14:00
QF: CAP-8469
£19.12
Customer Reviews

This is a replacement for one that broke down. It was very easy to fit because the electrical part was purely a plug in to the control box. The unions had been updated from the old type of pump so I only had to buy a new type of seal at very low cost. Very happy with its performance and would recommend this for a hot tub.
