Espa Circulation Pump - Wiper0 M-4P - 0.18HP

63mm Centre Suction x 63mm Centre Discharge

Extended 1 Year Warranty

In addition to the manufacturers standard warranty (usually 1 year) we also offer the opportunity for you to extend this warranty by a further 1 year (There is usually a one off fee to pay unless we are running a promotion) This can be arranged at the point of purchase or within a limited time afterwards.
Promotions - From time to time we run a promotiont to include a FREE 1year Extended Warranty on select products. If an item is eligible for a FREE extended warranty then this will be displayed on the product listing & will be noted in your basket.
An extended warranty is an easy way to protect your purchase, against any manufacturing defects causing breakdown. You will benefit from free repairs for the term of the warranty period & If your equipment can't be repaired then we will replace it free of charge.(A delivery surcharge may apply for non UK mainland addresses)
This warranty and the standard manufacturer’s warranty does not cover general wear and tear, abuse or misuse or incorrect installation.
If you would like any further information on our extended warranty scheme please call our Hydrospares team on 01326 371 483 OR email us at info@justspaparts.co.uk

LID: 19181
Wiper M-4P
Circulation Pump
0.18HP
1 ½" x 1 ½" (63mm x 63mm)
£248.71 Inc VAT
( £310.89)
PMP-5221
125397
2 In StockSame day dispatch if ordered by 14:00
Fast UK Delivery
Espa Circulation Pump - Wiper0 M-4P - 0.18HP
£248.71
RRP £310.89

Espa Wiper0 pumps are used as hot tub circulation pumps, but are more commonly found fitted in Whirlpool bath systems.

Quiet running, single speed, centre suction pumps for water recirculation with a central suction and rotatable wet ends.

Common on SpaForm Prestige hot tubs

Supplied with AMP cables.

We recommend re-using the cable from your old pump to ensure correct fitment to your spa pack if it differs from supplied cable.

Espa use BSP threads on the port connections. Please ensure correct unions are being used.

Model Information
Dimensions L x W x H 296x155x162mm
HEAD - H max 3m
FLOW - Q max 170 L/min
Type / Speed Circulation
Model Wiper0 M-4P
Horsepower 0.05-0.5 Hp
MPN 125397
Motor Information
Voltage / Frequency 230V / 50Hz
Amp Draw 0.6 A
Power - P1 0.13 kW
RPM 1380
Capacitor Size(s) 6 µF
Cord / Plug Type 3 Core AMP
Wet End (Tank) Information
Connection Type 1-1/2" Female BSP Thread
Wet End Information
Configuration Center Suction, Center Discharge
Connection Diameter 63mm
Thread Type Male - BSP
Downloads & Articles
More Info

Pump Specifications

Dimensions

  • 296 x 155 x 162 (mm)

Summary

  • Discharge: 1 ½"
  • Suction: 1 ½"
  • Water Temp: Max. 50ºC
  • HP: 0.18
